[evlatests] What does water do?
Rick Perley
rperley at nrao.edu
Mon Aug 14 16:05:55 EDT 2023
Water in the feeds causes a lot of problems. Very strongly affected is
the polarization.
Attached here are two plots -- showing the antenna cross-polarization
for a 'dry' antenna (ea01) and a 'wet' antenna (ea05).
Each shows the cross-polarization phase (narrow plots) and amplitude
(wider plots). Phase units are +/- 180 degrees. Amplitude units are 0
to 20% (actually, in tens of percent). These data were taken July 17.
Rob informs me that ea05 has been dried out since then.
ea01 shows the expected behavior -- fairly flat, some ripples,
amplitudes less than 8%.
ea05 is 'rather different'.
Similar behavior to ea05 -- but not nearly so extreme -- is seen in
ea11, ea18, and ea21.
Rick
-------------- next part --------------
A non-text attachment was scrubbed...
Name: X-ea01-Pol.png
Type: image/png
Size: 34491 bytes
Desc: not available
URL: <http://listmgr.nrao.edu/pipermail/evlatests/attachments/20230814/bce8cbe0/attachment-0002.png>
-------------- next part --------------
A non-text attachment was scrubbed...
Name: X-ea05-Pol.png
Type: image/png
Size: 45631 bytes
Desc: not available
URL: <http://listmgr.nrao.edu/pipermail/evlatests/attachments/20230814/bce8cbe0/attachment-0003.png>
